| System |
| CPU |
|
Support Intel® LGA 775 Core Duo / Core 2 Duo Pen-tium® 4 / Celeron® D processor with 65 nm processor technology |
| FSB |
|
533/800/1066 MHZ |
| BIOS |
|
Award 8MB |
| System Chipset |
|
Intel® Q965/ICH8 |
| I/O Chip |
|
Winbond W83627DHG-A |
| System Memory |
|
Two 240-pin sockets up to 4GB Dual Channel
DDR2 533/667/800 SDRAM |
| Watchdog Timer |
|
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step |
| Watchdog Timer |
|
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step |
| H/W Status Monitor |
|
Monitoring CPU temperature, voltage, and cooling fan status. Auto throttling control when
CPU overheats |
| Expansion |
|
One PCI Express x16 |
| S3 |
|
S3 Support |
| SmartFan Control |
|
Speed Cruise Mode |
| I/O |
| MIO |
|
1 x D-Sub, Gigabit LAN, 6 x USB 2.0, 2 x SATA,
2 x RS232, 2 x PS/2 (KB and MS), Audio |
| USB |
|
6 x USB2.0 |
| Display |
| Chipset |
|
Intel® 82Q965 GMCH integrated Graphics
Media Accelerator 30000 |
| Display Memory |
|
Intel® DVMT 4.0 supports 256 MB video memory |
| Resolution |
|
2048 x 1536 @ 32 bpp(@ 75Hz) |
| Dual Display |
|
CRT |
| Audio |
| Chipset |
|
Intel® ICH8 |
| AC97 Codec/Audio Code |
|
ADI 1882 5.1+2-CH HD Audio Codec |
| Audio Interface |
|
Mic in, Line in, Line out |
| Audio Amplifer |
|
TPA3005D2 Stereo 5 Watt per channel |
| Ethernet |
| LAN 1 |
|
Realtek RTL8111B PCI-E 1000Base-T Gigabit
Ethernet Controller |
| Back Panel I/O Port |
| Back Panel I/O Port |
|
* 1 x PS/2 Keyboard
* 1 x PS/2 Mouse
* 2 x RS-23
* 1 x VGA port
* 4 x USB 2.0/1.1
* 1 x RJ45 Port
* 5.1 CH Audio I/O (3 Jacks) |
| Internal I/O Connector |
| Internal I/O Connector |
|
* 1 x 20-pin ATX Power connector
* 2 x SATA connectors
* 1 x Front panel audio connector
* 1 x Audio amplifier connector
* 1 x System panel connect |
| Mechanical & Environmental |
| Power Type |
|
ATX |
| Operating Temperature |
|
0~60°C (32~140°F) |
| Operating Humidity |
|
0%~90% relative humidity, non-condensing |
| Size (L x W) |
|
6.69" x 6.69" (170 mm x 170 mm) |
| Weight |
|
0.88 lbs (0.4 Kg) |
